High Voltage 1-pin 500A 70-150mm2 HV plug Female connector ip67 battery connector high current HV connector
UPE company is a modern enterprise dedicated to the research and development, production and sales of industrial connectors for ten years.Our main business involves in push pull / plugging self-locking connector & cable assembly, M8 / M12 connector & cable assembly, new energy connector & cable assembly of automobile, energy storage connector & cable assembly, waterproof connector & cable assembly, circular connector & cable assembly, aviation plug / socket cable assembly, power connector and cable assembly, data connector and other types of connectors and cable assembly customized.
We sincerely look forward to cooperating with new and old customers, mutual benefit and win-win, improve the level of the industry, create a better future.
Our core value focuses on performance reliabilities and customer satisfaction.
We strive to be the an cost effective manufacturer for industrial connectors and cables.
-The ISO9001:2015 quality management system is a proven tool employed internationally to address such requirments.
-All our products are developed and delivered according to international standards, such as CE, UL, IEC, Rohns and Reach.
Product Advantages:
Temperature:-55℃-125℃
Rated Current:500A
Insulation Resistance:5000MΩ
Dielectric Withstand Voltage:5000V DC
Application: New Energy Vehicles, New Energy Industry, Energy Storage
Feature
* Touch-proof design
* Ingress protection: IP67
* 90° and 180° plugs options
* 360° shielded connection
* No tool required to unmate
* Multiple key options: X, Y, U, V
* Shield and unshielded plug options
* HVIL and temperature sensor options
Specfication
* Temperature: -55℃∽ +125℃
* Rated Current: 500A
* Insulation Resistance: 5000MΩ
* Dielectric Withstand Voltage: 5000VDC
* Mechanical Life: 500 times
* Salt Spray: 48 hours
* Ingress Protection: IP67
* WireRange: 95-95mm2, 120-12
Application
* DC-to-DC Converters
* AC/DC Charging Station
* Electric bus
* Electric motors
* High-current batteries pack
* Hybrid electric vehicles
* HV PDU
* PTC & Auxiliary
* PTC heater
* On-Board Charger (OBC)
* Inverters
Product Details
| Series | Connector Type | Number of Position | Rated Current | Cable size | HV Interlock | Shield function |
| KRX500 | Elbow plug Straight plug Socket | 1 | 500A | 95/120/135/150 mm² | Optional | Optional |
| KRX300 | Elbow plug Straight plug Socket | 1 | 300A | 35/50/70mm² | Optional | Optional |
| KRX60 | Plug Socket | 2 | 30A | 2.5/4/6/10mm² | Optional | Optional |
| KRX10 | Plug Socket | 1 | 200A | 25/35/50mm² | No | No |
| KRX10 | Plug Socket | 2 | 80a | 25/35/50mm² | No | No |
| KRX15 | Plug Socket | 3 | | 2.5/4/6mm² | No | No |
| KRX15 | Plug Socket | 4 | | 2.5/4/6mm² | No | No |
| KRX15 | Plug Socket | 19 | | 0.5/0.75/1mm² | No | No |
Production flow:
Packaging:
